RIX Optics Pocket K2 – Compact Thermal Power in Your Pocket
The RIX Optics Pocket K2 Thermal Imaging Monocular is designed for users who need reliable thermal detection in a compact, portable format. Lightweight and easy to carry, it delivers dependable performance for scanning, spotting, and observation in low-light and no-light conditions.
When observing wildlife, the Pocket K2 provides fast heat detection and clear imaging without the bulk of larger thermal devices.
256 Thermal Sensor with High Sensitivity
At the core of the Pocket K2 is a 256×192 VOx thermal sensor, designed to detect heat signatures quickly and accurately.
- 256×192 resolution (12µm pixel pitch)
- NETD <25mK for detecting subtle temperature differences
- Smooth 50Hz refresh rate for fluid image movement
This allows users to identify targets even in darkness, fog, or dense vegetation.
Portable & Lightweight Design
One of the standout features of the Pocket K2 is its size and weight:
- Weighs approx. 0.44 lbs (200g)
- Compact dimensions for easy storage
- Pocket-sized for carry in the field
Its ultra-portable design makes it ideal for long sessions where mobility matters.
Detection Range & Zoom Capability
Despite its small size, the K2 delivers solid performance:
- Detection range up to ~468 metres
- 1.7× optical zoom
- Up to 4× digital zoom
This combination makes it suitable for short- to mid-range scanning and observation.
OLED Display & Recording Features
The Pocket K2 includes a clear display and media functionality:
- 800×600 OLED display for sharp visuals
- Built-in photo and video recording
- 8GB internal storage
- Wi-Fi connectivity for mobile integration
These features allow you to capture and review observations easily.
Long Battery Life & Durable Build
Designed for real-world use:
- Up to 7 hours battery life (18650 battery)
- IP67 waterproof and dustproof rating
- Works in temperatures from -20°C to +50°C
This ensures reliability across a wide range of outdoor environments.
Key Features
- 256×192 thermal sensor with high sensitivity
- Detection range up to ~468m
- Compact, pocket-sized design (approx. 200g)
- 1.7× optical zoom + digital zoom
- OLED display with recording capability
- Up to 7 hours battery life
- IP67-rated durability
- Ideal for scanning, hunting, and observation
Frequently Asked Questions (FAQ)
1. What is the detection range of the Pocket K2?
It can detect heat signatures at distances up to approximately 468 metres.
2. How portable is the device?
It is extremely compact and lightweight (around 0.44 lbs), making it easy to carry in a pocket or bag.
3. Can it record video and images?
Yes, it includes built-in recording with internal storage and supports both photos and videos.
4. What battery does it use?
It uses a replaceable 18650 battery, providing up to 7 hours of runtime.
5. Does it work in bad weather?
Yes, the thermal sensor works in fog and rain, and the device is rated IP67 waterproof and dustproof.
6. Who is this device best suited for?
It is ideal for outdoor users who need a lightweight thermal scanning solution.
Sensor Specifications
Type: VOx Uncooled
Resolution: 256×192
Pixel Pitch: 12µm
NETD: <25 mK
Frame Rate: 50 Hz
Optical Specifications
Objective Lens: 9mm, F1.0
Magnification: 1.7~6.8×
Field of View (H×V): 19.4°×14.6°
Field of View, degrees/yd@100yd: 37.3 × 28.0 yd
Digital Zoom: 1~ 4×
Eye Relief: 13.5mm
Diopter Adjustment: -5D to +5D
Detection Range: 468m / 512yd
Display Specifications
Type: OLED
Resolution, pixels: 800×600
Video Recorder
Video / Photo Resolution: 800×600
Video / Photo Format: .mp4 / .jpg
Built-in Memory: 32GB
Physical Specifications
Degree of Protection, IP Code: IP67
Operating Temperature Range: -20? to +50? / -4°F to +122°F
Weight: 200 g / 0.44 lb
Dimensions: 124×46×74 mm / 4.9×1.8×2.9 in
Connections and Compatibilities
Battery Type: 18650
Operating Time on Battery Pack (at t=25?/72°F): 6 h
External Power Supply, V: 5V (Type-C USB)
